PGE104-3600/200-RBS1/1-N-3900

Part number

3806649

Deliverable within ca. - days Request replacement time loading...

In stock

Upon request You can make a product request by adding the item to your list and managing it in your myHYDAC area.

Piece

Technical data

Product Features
Ports	Pipe thread ISO
Position, ports 1	Radial
Seals	NBR
Shaft	Conical shaft 1:8
Mounting flange	Rectangular flange Ø50.8
Direction of rotation	Clockwise rotation
Displacement	36 cm³/U
Size	PGE104
Min. viscosity [cSt (mm²/s)]	16
Max. viscosity [cSt (mm²/s)]	200
Filtration	21/18/15
Oil temperature [°C]	-25 to +95
Hydraulic fluid	Normal hydraulic oil, Hydraulic oil type R&L

CAD data can’t be found at the product category level. Instead, it can be found directly at an individual product level.

Document type

Language

Product brochure EN
