ENS 3216-F31-0250-000-K
Part number
To the higher-level product group
923360
Deliverable within ca. -
days
Request replacement time
loading...
The replacement time depends on the product quantity.
Technical data
| Display | Yes |
|---|---|
| Measuring principle | Capacitive |
| Rod length [mm] | 250 |
| Measuring range [mm] | 170 |
| Switching outputs | 2 |
| Additional interface | 4 to 20mA (2 conductors), 0 to 10V, IO-Link |
| Mechanical connection | Tube 22 mm |
| Electrical connection | M12x1, 4-pole |
| Integrated temperature sensor | No |
| Approvals and certificates | UL approval |
Downloads
CAD data can’t be found at the product category level. Instead, it can be found directly at an individual product level.
Media
IODD-file_923360_ENS 3216-F31-0250-000-K
Software
EN
(0.04 MB)
