HLT 1100 – Analogue, digital, fully cylinder-integrated
HLT 1100-R2-L18-C01-0500-000

Skip to the end of the images gallery

main product photo

Skip to the beginning of the images gallery

HLT 1100-R2-L18-C01-0500-000

Part number

926884

Deliverable within ca. - days Request replacement time loading...

In stock

Technical data

Product Features
Design / geometry	Rod
Measuring range [mm]	500 mm
Resolution	0.1 mm
Output signal	4 .. 20 mA (3-conductor)
Mechanical connection	Cylinder-integrated, D=10 mm
Electrical connection	M12x1, single conductor 180 mm
Measuring principle	Magnetostrictive
Approvals and certificates	No

Downloads

CAD data can’t be found at the product category level. Instead, it can be found directly at an individual product level.

Document type

Language

EDS_926884_HLT 1100-R2-K02-F11-1325-019

Software EN

ZIP Download (0 MB)
