SR5E-01X/7,9 Q=7,9-8,9

Part number

710342

Deliverable within ca. - days Request replacement time loading...

Download CAD-Data

In stock

Technical data

Product Features
Adjustment type	Tool
Cavity	06020
Qmax valves [l/min]	20
Q product family [l/min]	0.3 - 20
Product family	SR5E
Flow rate range [l/min]	7.9 - 8.9
Function	Spool valve
Function	Flow control valve
Nominal size	6
Object designation	SR5E-01X/7,9 Q=7,9-8,9
Pmax [bar]	350
Control type	Direct-acting
Type of installation	Metric
Sealing material	FKM
Part number	710342
Design	Cartridge

Downloads

CAD data can’t be found at the product category level. Instead, it can be found directly at an individual product level.

Document type

Language

View CAD downloads

SR5E 2-Way Flow Regulator

Product brochure EN

PDF Download (0.36 MB)

Connection Housings for Cartridge Valves

Product brochure EN

PDF Download (0.7 MB)

Cartridge Valve Accessories

Product brochure DE, EN, FR

PDF Download (1.68 MB)

Conditions and Instructions for Valves

Product brochure EN

PDF Download (0.12 MB)

Conditions and Instructions for Valves

Product brochure EN

PDF Download (0.11 MB)
