HDA 4400 – Relative pressure, accuracy 0.5%, industry, mobile
HDA 44G5-A-0250-ENC-H00

Skip to the end of the images gallery

main product photo

Skip to the beginning of the images gallery

HDA 44G5-A-0250-ENC-H00

Part number

929095

Deliverable within ca. - days Request replacement time loading...

In stock

Technical data

Product Features
Type of pressure	Relative
Pressure unit	BAR
Pressure range min value	0
Pressure range max value	250
Accuracy	1.00% max = 0.5% typ.
Output signal	4 to 20mA (2 conductors)
Mechanical connection	G1/4 B DIN EN 837 / external
Electrical connection	DIN EN 175301-803 /3p + PE
Approval	ATEX, IECEx

Downloads

CAD data can’t be found at the product category level. Instead, it can be found directly at an individual product level.

Document type

Language

HDA 4400/4700 Ex ia ATEX IECEx for H2 User manual D/E

Operating/maintenance instructions DE, EN

PDF Download (6.54 MB)

HDA 4400 Pressure Transmitter for Hydrogen ATEX, IECEx: Ex ia / Ex nA / Ex ta

Product brochure EN

PDF Download (3.94 MB)

ATEX Approval KEMA05ATEX1016X E

Approval and certificate EN

PDF Download (2.27 MB)

IECEx Approval IECExKEM08.0014X E

Approval and certificate EN

PDF Download (1.32 MB)
